Light Gauge 1100 Aluminum Steel Coil 20mm H16 O Temper Hardness Pure Roll
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Color | Silver | Application | Transportation Tools, Door & Window, Glass Wall, Heat Sink, Decorations |
---|---|---|---|
Technique | Cold Drawn | Grade | 5000 Series |
Temper | O - H112 | Surface | Mill Finish |
Surface Treatment | Polished | ||
High Light | 20mm Aluminum Coils,1100 Aluminum Steel Coil,Hardness Pure Roll Aluminum Steel Coil |
Product Description
Light Gauge H14 H24 H16 O Temper Aluminio Hardness Pure Aluminium Roll 1100 Aluminum Steel Coil
Type | Chemical Composition For several alloys | ||||||||
Si | Fe | Cu | Mn | Mg | Zn | Ti | other | Al | |
1060 | 0.20 | 0.25 | 0.30 | 0.03 | 0.03 | 0.03 | 0.03 | 0.03 | 99.60 |
1050 | 0.25 | 0.40 | 0.05 | 0.05 | 0.05 | 0.05 | 0.03 | 0.03 | 99.50 |
3003 | 0.60 | 0.70 | 0.05-0.20 | 1.0-1.5 | 0.10 | 0.15 | Remain | ||
5052 | 0.25 | 0.40 | 0.10 | 0.10 | 2.2-2.8 | 0.10 | ------ | 0.2 | Remain |
Products Name | Aluminium Coil | ||
Alloy/Grade | 1050, 1060, 1070, 1100, 1200, 2024, 3003, 3104, 3105, 3005, 5052, 5754, 5083, 5251, 6061, 6063, 6082, 7075, 8011, 8079, 8021 | ||
Temper | F, O, H | MOQ | 5T for customized, 2T for stock |
Thickness | 0.014mm-20mm | Packaging | Wooden Pallet for Strip & Coil |
Width | 60mm-2650mm | Delivery | 15-25days for production |
Material | CC & DC route | ID | 76/89/152/300/405/508/790/800mm |
Type | Strip, Coil | Origin | China |
Standard | GB/T, ASTM, EN | Loading Port | Any port of China, Shanghai & Ningbo & Qingdao |
Surface | Mill Finish, Anodized, Color coated PE Film Available |
Delivery Methods |
1. By sea: Any port in China 2. By train: Chongqing(Yiwu) International Railway to Middle Asia-Europe |
Certificates | ISO, SGS |
Alloy Series | Typical Alloy | Introduction |
1000 Series | 1050 1060 1070 1100 | Industrial Pure Aluminium. In all series, 1000 series belongs to the series with the largest aluminium content. The purity can reach over 99.00%. |
2000 Series | 2024(2A12), LY12, LY11, 2A11, 2A14(LD10), 2017, 2A17 | Aluminium-copper Alloys. 2000 series is characterized by high hardness, in which the content of copper is the highest, about 3-5%. |
3000 Series | 3A21, 3003, 3103, 3004, 3005, 3105 | Aluminium-manganese Alloys. 3000 series aluminium sheet is mainly composed of manganese. The manganese content ranges from 1.0% to 1.5%. It is a series with better rust-proof function. |
4000 Series | 4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A | Al-Si Alloys. Usually, the silicon content is between 4.5 and 6.0%. It belongs to building materials, mechanical parts, forging materials, welding materials, low melting point, good corrosion resistance. |
5000 Series | 5052, 5083, 5754, 5005, 5086,5182 | Al-Mg Alloys. 5000 series aluminium alloy belongs to the more commonly used alloy aluminium series, the main element is magnesium, the magnesium content is between 3-5%. The main characteristics are low density, high tensile strength and high elongation. |
6000 Series | 6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02 | Aluminium Magnesium Silicon Alloys. The representative 6061 mainly contains magnesium and silicon, so it concentrates the advantages of 4000 series and 5000 Series. 6061 is a cold-treated aluminium forging product, which is suitable for applications requiring high corrosion resistance and oxidation resistance. |
7000 Series | 7075, 7A04, 7A09, 7A52, 7A05 | Aluminium, Zinc, Magnesium and Copper Alloys. The representative 7075 mainly contains zinc. It is heat-treatable alloy, belongs to super-hard aluminium alloy, and has good wear resistance. 7075 aluminium plate is stress-relieved and will not deform or warp after processing. |
