3-200mm Thickness Nm 450 Nm 400 Nm 500 Material Wear Resistance Hot Rolled Steel Plate Used for Ship Plate

  • 3-200mm Thickness Nm 450 Nm 400 Nm 500 Material Wear Resistance Hot Rolled Steel Plate Used for Ship Plate
  • 3-200mm Thickness Nm 450 Nm 400 Nm 500 Material Wear Resistance Hot Rolled Steel Plate Used for Ship Plate
  • 3-200mm Thickness Nm 450 Nm 400 Nm 500 Material Wear Resistance Hot Rolled Steel Plate Used for Ship Plate
Place of Origin China
Brand Name TONGMAO
Certification ISO9001 MTC
Model Number Wear Resistance Steel Plate
Minimum Order Quantity 5tons
Price Negotiable
Packaging Details Standard Packing
Delivery Time 7-15days
Payment Terms L/C, T/T
Supply Ability 500tons/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model NO. DC53 HRC60 ~ 62 Hardness 40hrb--95hrb
Sample Provide Base Material Cold/Hot Coil Steel
Thickness 3-200mm Width 1000mm-3000mm
High Light

High Toughness Wear Resistance Steel Plate

,

Cold Rolled Wear Resistant Steel Sheet
Leave a Message
Product Description

3-200mm Thickness Nm 450 Nm 400 Nm 500 Material Wear Resistance Hot Rolled Steel Plate Used for Ship Plate

3-200mm Thickness Nm 450 Nm 400 Nm 500 Material Wear Resistance Hot Rolled Steel Plate Used for Ship Plate 0

Wear resistant steel plate has high wear resistance and good impact resistance, capable of cutting, bending, welding, can take welding plug welding, bolt connection and other structures are connected with time in the maintenance process, convenient, widely used in metallurgy, coal, cement, electric power. Glass, mining, building materials, tiles and other industries, compared with other materials, has a very high price, has attracted more and more industries and manufacturers of all ages.

Commodity NM500 / AR500 hot rolled steel plate 8mm wear resistance steel plate
Size

Thickness: 3mm - 200mm

Width: 1000mm - 2500mm

Lenfth: 2000mm - 10,000mm

Special size can be cutted
Standard GB ASTM SSAB JIS
Grade

NM360 NM400

NM450 NM500

NM550 NM600

AR400

AR450

AR500

400 450

500 550

600

NK-EH360

JFE-EH400
Application Crusher, sieve plate, feeder, feed hopper, hoist, blade board, conveyor, bucket, knife board, gear, dump truck, scraper, industrial truck, rail truck, bulldozer, excavator. Pulp conveyor, screw conveyor, presses and so on
Payment T/T, L/C
Price Term FOB, CRF, CNF, CIF, EXW




Chemical Composition

Name C Si Mn P S Cr Ni Mo Ti B Als CEV
          less           more less
NM360 0.25 0.70 1.60 0.025 0.015 0.80 0.50 0.50 0.050 0.0005-0.006 0.010 0.48
NM400 0.30 0.70 1.60 0.025 0.010 1.00 0.70 0.50 0.050 0.0005-0.006 0.010 0.57
NM450 0.35 0.70 1.70 0.025 0.010 1.10 0.80 0.55 0.050 0.0005-0.006 0.010 0.59
NM500 0.38 0.70 1.70 0.020 0.010 1.20 1.00 0.65 0.050 0.0005-0.006 0.010 0.64
NM360 and NM400, Si and Mn composition can be enhance to 2.00% and 2.20%.

FAQ:
Q:Can you send samples?
A:Of course, we can send samples to all parts of the world.


Q:What are the shipping ports?
A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao ports, you can choose other ports according to your needs.

Q:What are the certifications for your products?
A:We have ISO 9001, SGS, EWC and other certifications.

Q:How long does your delivery time take?
A:In general, our delivery time is within 7-15 days, and may be delayed if the demand is extremely large or special circumstances occur.

Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.

Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.

Q:How to pack the products?
A:The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation wooden pallet. It caneffectively protect products from corrosion during ocean transportation.Send your message to this supplier
