Hot Rolled Nm 400 Nm450 Nm500 High Strength Wear Resistance Steel Sheet Customized Used for Cutting Tools

  • Hot Rolled Nm 400 Nm450 Nm500 High Strength Wear Resistance Steel Sheet Customized Used for Cutting Tools
  • Hot Rolled Nm 400 Nm450 Nm500 High Strength Wear Resistance Steel Sheet Customized Used for Cutting Tools
  • Hot Rolled Nm 400 Nm450 Nm500 High Strength Wear Resistance Steel Sheet Customized Used for Cutting Tools
Place of Origin China
Brand Name TONGMAO
Certification ISO9001 MTC
Model Number Wear Resistance Steel Plate
Minimum Order Quantity 5tons
Price Negotiable
Packaging Details Standard Packing
Delivery Time 7-15days
Payment Terms L/C, T/T
Supply Ability 500tons/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Surface Treatment Mill Finish Or As Required Technique Hot Rolled
Model NO. NM500 / NM450 Stock Stock
Width 1000mm - 2500mm Thickness 3mm-200mm
High Light

8mm Wear Resistance Steel Plate

,

Abrasion Resistant Steel Plate Ar500

,

Nm500 Abrasion Resistant Steel Plate
Leave a Message
Product Description

Hot Rolled Nm 400 Nm450 Nm500 High Strength Wear Resistance Steel Sheet Customized Used for Cutting Tools


 Implementation of the standard: GB/T24186-2009 or technical agreement.

 Delivery status: quenching or quenching+tempering



steel name wear resistant steel plate
steel grade NM360 NM400 NM450 NM500 NM550 NM600
thickness 6-120mm 6-120mm 6-120mm 6-70mm 6-70mm 6-60mm
tensile strength/Mpa ≥1100 ≥1200 ≥1250
enlongation/% ≥12 ≥10 ≥7
-20ºC longitudinal impact value/J ≥24 ≥24 ≥24 ≥24
hardness/HB 330-390 370-430 420-480 ≥470 ≥530 ≥570


Chemical Composition

Name C Si Mn P S Cr Ni Mo Ti B Als CEV
          less           more less
NM360 0.25 0.70 1.60 0.025 0.015 0.80 0.50 0.50 0.050 0.0005-0.006 0.010 0.48
NM400 0.30 0.70 1.60 0.025 0.010 1.00 0.70 0.50 0.050 0.0005-0.006 0.010 0.57
NM450 0.35 0.70 1.70 0.025 0.010 1.10 0.80 0.55 0.050 0.0005-0.006 0.010 0.59
NM500 0.38 0.70 1.70 0.020 0.010 1.20 1.00 0.65 0.050 0.0005-0.006 0.010 0.64
NM360 and NM400, Si and Mn composition can be enhance to 2.00% and 2.20%.

Advantages of wear plates

1. Good impact resistance

The wear-resistant composite steel plate is made of low-carbon steel or low-alloy, stainless steel and other tough materials as the base material. The metal material not only has good wear resistance, but also can withstand impact and wear such as falling from a height during the transportation process.

2. Good heat resistance

The alloy wear-resistant layer is made of vanadium, molybdenum and other alloy materials in the production process, so it can be used and worn at a high temperature of ≤800 °C. Compared with ordinary carbon steel substrates, it can only be used below 380°C, and low-alloy heat-resistant steel sheets work below 540°C. This shows how high the heat resistance coefficient of the wear plate is.

3. Good corrosion resistance

The wear-resistant plate contains a large amount of metallic chromium, so it has good anti-rust and anti-corrosion properties. It is especially suitable for the use of coal drop drums and funnels. Not only solid and firm, but also to prevent coal sticking.

Hot Rolled Nm 400 Nm450 Nm500 High Strength Wear Resistance Steel Sheet Customized Used for Cutting Tools 0

FAQ



Can you send products to my country?

Sure, we can. If you do not have your own ship forwarder, we can help you.

Will you delivery the goods on time?
Yes,we promise to provide best quality products and delivery on time no matter if the price change lot or not.Honesty is our company's tenet.

How can I get a quotation from you ?
You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager.
And you can also find our contact information on contact page.

How do you make our business long-term and good relationship?
1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them

Please contact me for more info today!

SHANDONG TONGMAO SPECIAL STEEL CO.,LTD
