Abrasion Resistance Steel Plates Nm360 Nm400 Nm450 Nm500 12mm 14mm 16mm 20mm 15mm

  • Abrasion Resistance Steel Plates Nm360 Nm400 Nm450 Nm500 12mm 14mm 16mm 20mm 15mm
  • Abrasion Resistance Steel Plates Nm360 Nm400 Nm450 Nm500 12mm 14mm 16mm 20mm 15mm
Place of Origin China
Brand Name TONGMAO
Certification ISO9001 MTC
Model Number Wear Resistance Steel Plate
Minimum Order Quantity 5tons
Price Negotiable
Packaging Details Standard Packing
Delivery Time 7-15days
Payment Terms L/C, T/T
Supply Ability 500tons/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model NO. AR360/AR400/AR450/AR500/AR600 Stock Stock
Steel Grade Nm360 Nm400 Nm450 Nm500 Nm550 Nm600 Width 1500-3500mm Or Cut-to-Size As Customer
Thickness 4-150mm Heat Treatment Tempering ( Quenching + Backing)
High Light

Nm360 Abrasion Resistance Steel Plates

,

Wear Resistant Steel Plate Nm500
Leave a Message
Product Description

Abrasion Resistance Steel Wear Plates Nm360 Nm400 Nm450 Nm500 12mm 14mm 16mm 20mm 15mm

Thickness: 0.2-500mm,etc
Width : 1000-4000mm,etc
Length: 2000mm, 2438mm, 3000mm, 3500,6000mm,12000mm,or rolled,etc etc
Standard: ASTM,AISI,JIS,GB, DIN,EN
Surface: Black painted,PE coated,Galvanized,color coated,
anti rust varnished,anti rust oiled,checkered,etc
Technique: Cold Rolled, Hot Rolled
Certification: ISO, SGS
price terms: FOB,CRF,CIF,EXW all acceptable
Delivery Detail: inventory About 5-7; custom-made 25-30
Loading port: any port in China
Packing: standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
Payment Terms: T/T, L/C at sight
Container size: 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)

Wear-resisting board is what material?

1, The main material is steel, wear-resistant plate was mostly low carbon steel and alloy wear-resisting layer, the alloy wear-resisting layer 1/2 - one-third of occupying the whole board thickness, the main chemical composition is chrome. So I can achieve all material content is 20% ~ 30%, the surface hardness is very high, and wear-resisting performance is very good, long service life.

2, Wear-resisting board is mainly used in many factories, at the same time will also bring to use as transmission, because of its resistance to impact is very strong, so the articles of height difference is bigger, will not deformation, because it itself has very good corrosion resistance, so no matter what is transmitted items it can keep a good life. In respect of processing wear-resistant plate weldability is also relatively strong, very convenient bay area is in the shape of various so the machining is more convenient.

Wear-resistant plate 400 and wear-resistant plate 500 difference?

1, The first is the difference between the two different hardness value range, NM400 hardness requirements between 360-440; And the hardness requirement of NM500 between 480-550. Followed by cutting processing technology is different, the welding performance requirements are also different, * is the difference in price.

2, Wear resistant alloy steel is metallurgical combination between layer and matrix. Through special equipment, automatic welding technology and high hardness alloy welding welding evenly in the substrate. Composite layer number is 1 ~ 2 ~ layers, in the process of the composite alloy contraction ratio is different, lead to uniform transverse cracks are the prominent characteristics of wear resistant steel plates.

Abrasion Resistance Steel Plates Nm360 Nm400 Nm450 Nm500 12mm 14mm 16mm 20mm 15mm 0

NM500 wear plate and NM360 wear-resistant plate what purposes

NM500 wear-resistant plate, high wear resistance, machinability is good, after annealing machinability is 50% poor weldability, cold become low plasticity, low hardenability, water quenching cracks easily, but there was no tempering meng, general in normalizing or quenching + tempering and high, use after induction rate of fireMainly used in the manufacture of moving load and impact load is not big and good abrasion resistance requirement of mechanical parts, such as forging gear, shaft friction plate, machine tool spindle, engine crankshaft, roll, tie rod, spring washer, not important spring, farm machinery and deep soil of plowshares, shovels, overloaded spindle and shaft parts

NM360 wear-resistant plate, high wear resistance, low plasticity and toughness, high strength, high hardness can be obtained after heat treatment, processability, medium, low hardenability, quenching cracks of the tendency in the water, weldability and cold deformation properties are low, generally in normalizing or quenching + backAfter the fire use www.docin.comMainly used in the manufacture of wear resistance, high mechanical strength and elastic parts, parts can also be used to make steel, such as connecting rod, gear, motorcycle tyre and rim, shu, roll, flat spring
