Nickel Alloy 0.5mm Centrifugal Casting Tube Seamless Or Welded

Place of Origin China
Brand Name Stainless Steel Pipes
Certification ISO9001
Model Number Tongmao
Minimum Order Quantity 3 Tons
Price $530 per ton
Packaging Details Sea Worth Packaging or Client's Request
Delivery Time 5 - 15 Working Days
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 500 Tons - 1 Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Standard ASTM, GB, DIN, JIS, API, EN Thickness 0.5mm - 20 Mm
Application Fluid Pipe, Structure Pipe, Construction, Boiler Pipe, Chemical Industry Grade 20#, A53 (A,B), 45#, Q345
Technique Hot Rolled, Cold Rolled, Extruded Length 1000mm - 12000 Mm
High Light

0.5mm centrifugal casting tube

,

nickel alloy centrifugal casting tube

,

0.5mm nickel alloy tube

Leave a Message
Product Description

Top quality stainless steel/Nickel alloy,Titanium alloy tube ,Centrifugal casting Tube, seamless or welded pipe produce and supply random length

Detailed pipes we could supply:

seamless pipe Round pipe Out diameter: 1/8"-24"(6mm-630mm).
Wall thickness: ANSI 5S-160S (0.9mm-100mm)
Square pipe   20x20x-200x200:thickness2-50mm
rectangular pipe   10x20-150x100,thickness:2-50mm
Hex pipe Out hex or Round
Inside bore or hex
Flat to flat 16-70mm,
thickness:3-10mm
With drawing
Oval tube   With drawing
Welded type Round pipe Out diameter: OD6-2500MM
Wall thickness: Thickness:1-50mm
Square pipe   10x10-200x200,thickness1-3mm
Rectangular pipe   10x20-150x100,thickness:1-3mm
Oval tube   As drawings
Manufacture Standard: ASTMA213/312/269/511/789/790,
GOST9940/9941,DIN17456/17458/EN10206/17440
JIS3459/3463,GB13296/14976/9948/5310/8142/8143
stainless steel TP304,304L,304H,304N,316,316L,316Ti,317L,310S,321,321H,347H,S31803, S32750,347,330,825,904L,
12X18H9,08X18H10,03X18H11,08X18H10T,20X25H20C2,08X17H13M2T,08X18H12E
1.4301, 1.4306, 1.4401, 1.4404, 1.4435, 1.4541, 1.4571, 1.4563, 1.4462, 1.4845,
SUS304, SUS304L, SUS316, SUS316L, SUS321, SUS310S etc.
Nickel alloy

Hastelloy: UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230, R30556

Inconel: UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926

Monel: UNS N04400, N05500

Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH

Nickel: N4/UNS N02201, N6/UNS N02200

Titanium and titanium alloy GR1,GR2,GR5,GR7,GR9,GR12
Centrifugal casting tube 57-1200mm OD
Cobalt alloy pipe customed sizes
Process methods: cold drawn, cold rolling,welded
Surface & Delivery condition: Solution annealed and pickled, grey white (polished),with plain ends/bevel edges ends,Hairline
Length: Max25 meters
Packing: in seaworthy wooden cases or in bundles
Min order quantity: 0.5 ton each size for common steel.
Delivery date: soonest or discussible
Certificates: ISO9001:2000 quality system and Mill test Certificate supplied

Our Products Rang:
Steel pipe,Stainless Steel bars, Pipes & Tubes - Welded, Seamless Duplex Steel Pipe And Fittings
Fasteners
Wire rope and rope fittings
Nickel Alloy Steel Pipe And Fittings
Titanium Pipe and Titanium Bars,Flanges, Fitting
Centrifugal casting tube

Material supply
Stainless Steels - 304, 304H, 304L, 316, 316H, 316L, 321, 321H, 347, 310, 410, 410S, 904L etc
Duplex Steel - UNS 31803 (Duplex), UNS 32750 / UNS 32760 (Super Duplex)/2205 etc
Nickel Alloy Steel- Alloy B/ N10001, Alloy B2/N10665, Alloy B3/N10675, Alloy C4/N06455, Alloy C22/N06022, Alloy C276/N10276, Alloy C2000/N06200, Alloy G35/N06035, Alloy G30/N06030, Alloy S/N06635, Alloy N/N10003, Alloy X/N06002, Alloy 188/R30188, Alloy 230/N06230, Alloy 556/R30556 Alloy 600/ N06600, Alloy 601/N06601, Alloy 617/N06617, Alloy 625/N06625, Alloy 718/N07718, Alloy X750/N07750, Alloy 800/N08800, Alloy 800H/N08810, Alloy 800HT/N08811, Alloy 825/N08825, Alloy 925/N09925, Alloy 926/N08926/Alloy 400/ N04400, Alloy K500/N05500
Precipitation-hardening Steels- 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH
Nickel: N4/UNS N02201, N6/UNS N02200
Titanium :TA1 TA2 TC4, ASTM B337,ASTM B338,ASTM B861,ASTM B862

Cobalt alloy:umco50
Centrifugal casting pipes,reformer tube,radiant tube,heat resistant steel etc


General Require of ASTMA213/M

standard
Items
ASTM A213/A213M


Steel grade

TP301 TP304L
TP316 TP316L
TP317 TP310L
TP347 TP310S
TP347H△ TP310H *
TP309H* TP321H△
Rp0.2(Mpa) ≥170 ; ≥205
Rm(Mpa) ≥485 ; ≥515
A(%) ≥35
Flatten experiment(mm) H=1.09t/(0.09+t/D)
flaring test Inside diameter 21-68%
Grain size "*"," △ "ASTM E112/ "△ "7#or above7#"*"6#or above6#

hydrostatic test (Mpa)
D Pmax

P=220.6t/D
  <25.4 7
  25.4-<38.1 10
  38.1-<50.8 14
  50.8-<76.2 17
  76.2-<127 24
  ≥127 31
Crystal
corrosion test
ASTM A262
nondestructive inspection ASTM E213 E309 E426
Heat treatment (solid solution) required


Out-diameter tolerance(mm)
OD TOLERANCE
  <25.4 ±0.10
  25.4-≤38.1 ±0.15
  >38.1-<50.8 ±0.20
  50.8-<63.5 ±0.25
  63.5-<76.2 ±0.30
  76.2-≤101.6 ±0.38
  >101.6-≤190.5 ±0.38/-0.64
  >190.5-≤228.6 ±0.38/-1.14

Thickness tolerance(mm)
OD TOLERANCE
  ≤38.1 +20%-0
  >38.1 +22%-0
straightness(mm/m) REASONABLE
HARDNESS HRB<90

Parts of workshop:


Quality assure of stainless steel pipe tube:
1)Basic guarantee:Raw material guarantee,we use the Tsingshan Brand raw material,the quality is good,adding we use the spectrum direct-reading test,our professional
workers &equipments,we could guarantee the tubes is right of the clients' needs.

2)Process control:follow the process chart + our professional workers' care

3)Inspection& Test:
Direct-reading Spectrum Instrument analytic for chemical composition, Yield Strength, Tensile Strength, Elongation, Hardness Test, Flattening Test,Flaring Test, Eddy Current Test, Ultrasonic Test, Hydrostatic Test, Corrosion Test, etc


Features of stainless steel tubes:

1)characters such as Safety, health, environmental protection

2)economy applicable, good surface

3)the resistant to corrosion

4)less weight than bars, thickness and out diameter so variously

5)easy cutting, huge deformation

6)tensile strengthen and good be flexible etc.

Applications & Usage of seamless stainless,nickel,titanium pipe:
as Line pipe, boiler pipe, mechanical structure, hydraulic prop pipe, gas pipe, geological pipe, chemical pipe
(high pressure chemical fertilizer pipe, oil cracking pipe) and tube for ships, etcdecoration,building,construction,water pipe,petroleum, chemical industry, chemical fiber, smelt, medical machinery,paper making,Heat preservation and refrigeration, mechanical equipment, food, electricity, water conservancy,architecture, aerospace, navigation shipbuilding, environmental protection and boiler heat exchanger

Package and delivery:
Welcome to contact us for pipe inquiry, One stop service for all pipes
One address: songalloy.en.made-in-china.com, service forever!
